CeramicSpeed BB ALPHA Krankboks for BB30 Shimano Road

This CeramicSpeed BB ALPHA bottom bracket is the ultimate technical solution for riders seeking maximum performance on their road bike equipped with a BB30 frame. To ensure a correct and smooth installation, special attention must be paid to two primary factors: the frame's bottom bracket standard and the crankset to be mounted. This specific model is precision-engineered for the BB30 standard, meaning it is designed to fit perfectly in frames where the bottom bracket shell has an internal diameter of exactly 42 mm and a width of 68 mm. When it comes to the crankset itself, this unit is created to function flawlessly with 24 mm axles. This makes it the ideal upgrade for riders using Shimano Road cranksets, as these utilize the well-known 24 mm spindle standard. By integrating a Shimano crankset into a BB30 frame via this ALPHA bottom bracket, an extremely stable and efficient power transfer is achieved. The advanced manufacturing process ensures that all tolerances are minimized, which not only optimizes every single pedal stroke but also eliminates the risk of the annoying creaking sounds that can otherwise occur in press-fit systems. Whether you are building a completely new road bike from scratch or wish to upgrade your current setup, this configuration provides a technically superior platform that combines Shimano's legendary reliability with CeramicSpeed's unmatched bearing technology and low friction.

What truly sets the CeramicSpeed ALPHA series apart from other bottom brackets on the market is the uncompromising approach to material selection, weight optimization, and advanced engineering. At the heart of the system are the specially developed bearings, which combine races made of hardened stainless steel with world-renowned CeramicSpeed balls made of grade-3 silicon nitride. This unique combination was chosen to achieve unsurpassed corrosion resistance without compromising on the extremely low friction required at the professional level. By using stainless steel, it is ensured that the bearings can withstand moisture, rain, and harsh road conditions without rusting, while the ceramic balls—which are significantly harder, rounder, and smoother than traditional steel balls—markedly minimize energy loss in the pedal stroke. Another significant improvement in the ALPHA model is the optimized bearing cups in lightweight 7075-aluminum. These have been redesigned to be 10% lighter than the previous models, bringing the overall weight down to a minimum without sacrificing strength. The protection is also in a class of its own, thanks to the newly developed light-contact seals with stainless steel backing. These seals provide up to 500% better protection against contamination from dust and water compared to standard solutions. To ensure the best performance from the first kilometer, the bottom bracket is supplied pre-lubricated with CeramicSpeed UFO All Round Grease, which is formulated to balance the lowest possible friction with long-lasting durability under all imaginable weather conditions.

The durability and reliability of the CeramicSpeed BB ALPHA are not merely based on theoretical calculations but are the result of some of the most extensive tests in the history of the cycling industry. The product has been thoroughly validated through more than 1,000,000 test kilometers on the road, which corresponds to many years of intensive use for even the most dedicated enthusiasts or professional athletes. To test the absolute limits, the bottom bracket has also undergone extreme laboratory tests with continuous loads for 7 hours at a constant power of a full 3000 watts. This clearly proves that the unit can handle even the most powerful sprinters' maximum output without giving way or losing its mechanical efficiency. The technical construction also features a service-friendly design; the updated dust covers make it easier than ever to maintain the bearings, ensuring optimal performance year after year. As the ultimate proof of quality and confidence in Danish craftsmanship, CeramicSpeed offers a lifetime warranty on this ALPHA bottom bracket. This means that as long as the system is maintained correctly according to the instructions, you are covered against manufacturing defects and material failure throughout the lifetime of the product. This warranty is unique in the industry and emphasizes that the investment in an ALPHA bottom bracket is a long-term solution for your bike. Reliability is further supported by the fact that the technology is validated by professional teams such as Soudal Quick-Step and Cannondale Factory Racing, guaranteeing a component that is faster, lighter, and more robust against the challenges that both weather and terrain can present.
